Welcome to the DFS API

The DFS API catalog provides interested parties, such as implementation partners, an insight into our API offering so that solutions can be designed based on these focussing on the functionalities required to build Hybrid Wealth Management solutions. The target audience is primarily software engineers and business analysts with know-how in the finance industry and specifically the wealth domain.

This portal will continuously grow to be the main resource for docs, guides, cookbooks and examples for additiv’s DFS API products and services.

The DFS APIs are the backbone of the solution and are used by the standard B2B and B2C web applications created by additiv. Specifically, the Wealth APIs are the backbone of additiv’s Hybrid Wealth Management offering.

Introduction

DFS services expose a RESTful API that aims to speak the business domain language while hiding the business logic complexity from the consuming systems.

Multiple API hosts

DFS exposes multiple API groups, each serving different purposes. Different API groups may reside under different hosts while a single group may serve 1-n hosts.

API Gateway

In a microservices architecture, client apps usually need to consume functionality from more than one microservice / host. If that consumption is performed directly, the client needs to handle multiple calls to microservice endpoints. (source: The API gateway pattern versus the Direct client-to-microservice communication)

DFS APIs continuously evolve and new microservices / hosts are introduced or existing microservices are updated. This, among many other reasons is why live APIs are accessed by client apps via an API gateway.

For simplicity, this portal shows both read-only and mutating endpoints in the standalone form and not under the API gateway. Therefore, the grouping of the endpoints (e.g. Wealth, Dms) is insignificant and done for practical reasons.

Getting Started

All consumers using the DFS APIs (e.g. client applications, postman users etc.), must be uniquely identified and authorized to access DFS endpoints regardless if there is an authenticated person.

Each consumer might be authorized to access a specific sub-set of endpoints based on the app needs and usage.

This is achieved via a set of credentials provided to every consumer of the APIs (referred to as Client App) which identifies the App and allows the system to determine the scope(s) and access policy group(s) assigned to it.

  • Client ID (i.e. username of the app)
  • Client Secret (i.e. password of the app to match the Client ID)

Since DFS APIs are designed for multi tenancy, these credentials also allow the system to identify the tenant(s) which the App is authorized to access.

All endpoints that require such authorization (the vast majority) are protected with a Bearer Authorization token (JWT) and require the caller to pass the string Bearer {JwtAccessToken} in the Authorization header.

Obtaining Access Token

A client application can easily obtain the needed token by issuing a request to the connect/token endpoint of DFS identity server with valid app credentials, the required scope, grant_type etc. Depending on the requirements and permissions, different token types can be requested (e.g User token, App token). For example:
{
scope: "DfsApi",
grant_type: "client_credentials",
client_id: "v072tGsxjdsaTuZlzil7TnDUAqr5d3",
client_secret: "XMevpAsNKckL7Z3veXkayxgaleQLEp",
tenant_uid: "X101XX1X-0X1X-1X0X-X0XX-X10X10X101XX"
}

Playing with the APIs

The API portal does not offer, at this point, ability to get access keys and execute calls against the endpoints. To get access to a running system with live APIs, please contact us with your specific needs.

Not a developer?

Contact us to schedule a demo of our standard Hybrid Wealth apps to learn what can be achieved with these APIs and how additiv can solve your business needs.

The endpoints provided in this portal are not a guarantee of service. Partners authorized to access a live system will get regular updates which includes new and updated APIs. This portal is updated regularly but less frequently.

License & Terms of Use

The additiv DFS API catalog can only be used by additiv’s internal engineering teams or by licensed parties under a license agreement containing restrictions on use and disclosure. The DFS software and documentation, including the APIs, are protected by intellectual property laws. additiv’s objective is to focus on developing robust APIs as it designs and further develops the available services. The APIs may change in the course of architectural improvements, addition of capabilities, and optimization of performance. The API endpoints provided in this portal are not a guarantee of service. Parties authorized to access a live system will get regular updates which includes new, deprecated and updated APIs and in some cases, APIs might also be removed. Except as expressly permitted in individual license agreements or allowed by law, you may not use, copy, reproduce, translate, broadcast, modify, license, transmit, distribute, exhibit, perform, publish or display any part of the content on this site / document, in any form, or by any means.

Last update: DFS version 2024.4
